Specifications
for the WideTEK 12 Flatbed Scanner
Maximum Scan Area
12.5 x 18.5 inches
Scanner Resolution
1200 x 1200 dpi
(optionally 9600 x 9600 dpi interpolated)
Scanning Speeds
Color: 12.5 x 18.5 inches@300 dpi
3 Seconds
Maximum Media Thickness
N/A
Autoformat Size Recogntion
yes, crop and deskew
Data Capture (color/mono)
48-bit color / 16-bit grayscale
Scan Ouput
24 bit color, 8 bit grayscale, bitonal, enhanced halftone
ICC Profiles
Embedded for sRGB, Adobe RGB and native.
File Formats
Multipage PDF (PDF/A) and TIFF, JPEG, JPEG 2000, PNM, PNG, BMP,
TIFF (Raw, G3, G4, LZW, JPEG), AutoCAD DWF, JBIG, DjVu,
DICOM, PCX, Postscript, EPS, Raw data
Interface
Gigabit Ethernet (RJ45), USB 3.0
Camera
Tri-Color CCD Camera, 22,500 pixels, encapsulated and dust-proof
Light Source
Two lamps with white LEDs, integrated optical diffusor
Computer
64 bit Linux, Intel quad core processor, 8 Gigabyte RAM, 320GB HDD for extra large jobs.
Touchscreen
7 inch color WVGA (wide VGA) touchscreen
Power
Requirements
100-240 V AC, 47 - 63 Hz
Power Consumption
0.5 W (Sleep) / approx. 2.5 W (Standby) / 28 W (Ready to scan) / 55 W (Scanning)
Weight & Dimensions
HxWxD
(8.7 x 17.4 x 31.3 inches)
62 Lbs.
Operating Temp
5 to 40 °C (40 to 105 °F)
Relative Humidity
20 to 80% (non-condensing)
Noise
Less than 42 dB(A) (Scanning)
Less Than 32 dB(A) (Standby)
Approvals
IEC 62386-1, UL62368-1, CSA C22,2#62368-1; CB, CE, FCC, BIS, CCC, RoHS
