S5160 Series Scanner
 Specifications

S5160

		- 160 ppm/320 ipm
- Daily Duty Cycle: Unlimited
- List:$33,300


	S5180

		- 180 ppm/360 ipm
- Daily Duty Cycle: Unlimited
- List:$50,000


		S5210

		- 210 ppm/420 ipm
- Daily Duty Cycle: Unlimited
- List:$88,900



Camera Technology
Dual White LED Illumination CCD; Grayscale output bit depth is 256 levels (8-bit); color output bit depth is 24 bits (8 x 3); color capture bit depth is 48 bits (16 x 3)

Optical Resolution
600 dpi Optical and Output

Lighting Technology
Dual White LEDs -instant warm-up; designed to last the life of the scanner with normal use.

Image Enhancement
Award winning Perfect Page Imaging features

Output Resolution
100, 150, 200, 240, 300, 400, 600 dpi

Maximum Document Size
width: 12"x17" Long Doc. mode: up to 160 inches

Minimum Document Size
(2. in. x 2. in.)

Paper Thickness and Weight
Automatic 750-sheet elevator design; automatic document feeder with four settings: continuous feed, 100-sheet, 250-sheet, 500-sheet and full 750-sheet batches
With ultra-lightweight feeder accessory: 25 g/m2 (7 lb.) rice paper to 75 g/m2 (20 lb.) bond

Feeder
Automatic 750-sheet elevator design; automatic document feeder with settings: continuous feed, 100, 250, 500-sheet and full 750-sheet batches

Multi-feed Detection
With ultrasonic technology, five sensors

Interface
USB 3.2 Gen 1x1 Compatible, 10/100/1000 Ethernet

 Output File Formats and Destinations.
BMP / JPEG / Single-page TIFF / Multipage TIFF / PDF/A-2b / PNG / RTF / XLSX, DOCX, PPTX
FADGI Mode: Uncompressed Single-Page TIFF (300DPI)

Operator Control Panel
9.3 in. (235mm) control panel with 7.5 in. (190mm) Graphical color touchscreen LCD with operator control buttons

Features
Intelligent Document Protection with 3 sensors, interactive Operator Control Panel (OCP), barcode reader, interactive multifeed ignore with image display on host, Intelligent Imprinting (patch counting), streak filtering, controlled stacking, Perfect Page technology, iThresholding, automatic color detection, autocrop, image edge fill (black or white), aggressive crop, deskew, content-based blank page detection and deletion, multi-color dropout, hole fill, dual-stream scanning, automatic orientation, color-on-the-fly toggle patch, and much more.

Archival Standard Compliance
FADGI 2023: Documents (Unbound): General Collections 3-Star
    FADGI 2023: Documents (Unbound): Modern Textual Records

Data Security
This scanner processes scanned data exclusively through volatile memory ensuring image data is effectively erased upon shut down.

Additional Options
Pre- and/or post-scan imprinter, Feeder Consumable Kit, Flatbed, Manual Feed shelf, Rear Exit tray, Switchable background, Imaging guide set, Carrier Sleeves.

Warranty (US and Canada)
90 days on site included.
Up to 5 year warranty options available.

Certifications
Achieved the status of EPEAT® Gold Registered and meet RoHS compliance standard which restricts the use of hazardous substances and waste products.

Electrical Requirements
100-240V (International); 50-60 Hz

Power Consumption
Low power mode: 23.7 Watts;
 Running Maximum: 240 Watts
 Standby Minimum: .5 Watts

Environmental Factors
Operating temperature: 50-100° F
 Operating humidity: 10% to 80% RH

Supported Drivers (Included)
TWAIN, ISIS, WIA drivers. Also Kofax Certified (not included)

Supported Operating Systems
64-bit: Windows 10, 11, Windows Server 2019, 2022


Recommended PC Configuration
Intel Core i5 (Gen 12 or newer),  USB port 3.2 (Super Speed) or 2.0 (High Speed) • 8 GB RAM or more

Accoustical Noise
Standby <39 dB
 Scanning <68 dB

Dimensions
s5160/s5180: Weight: 132 lbs.
 (DxWxH)
 (22"(depth) x 27.3" x 17 inches tall)
    s5210: Weight: 432 lbs.
 (DxWxH)
 (32"(depth) x 27.3" x 42 inches tall) (with stand)
